The MP128 is a controller for sending MIDI program change information on any of the 16 standard MIDI channels. This is done in 10's and 1's, or it can be thought of as 12 banks of 10. The 3-digit display shows the MIDI program number. The MP128 is a simple device to use, extending the flexibility of any MIDI controlled device. |
|
Specifications |
| Size | 17" X 5" X 1.5" (381 x 127 x 38 mm) |
| Weight | 3 lbs. (1.4 kg) |
| Power | 7 - 15 VAC/VDC 80 mA |
| Phantom Power | 7 - 25 VDC 80 mA, pin 1 neg, pin 3 pos. |
| Display | 3 digit red, .56" high efficiency |
| Output | Standard MIDI Program Change, Song Start/Stop |
| Output Jacks | 2 5-pin DIN jacks (MIDI OUT, MIDI SHARE) |
| Chassis | Black painted steel |
